Yamaha UD-WL01 USB Wireless LAN Adaptor

incl. VAT
Ask us about our Price Promise - click here
UD-WL01 USB Wireless LAN Adaptor
UD-WL01 USB Wireless LAN Adaptor UD-WL01 USB Wireless LAN Adaptor UD-WL01 USB Wireless LAN Adaptor


The UD-WL01 Wireless LAN Adapter allows you to connect compatible Yamaha musical instruments to a home WiFi network. Depending on the instrument, this may allow you to connect compatible apps running on smart devices to the instrument or, in some cases, connect the instrument to web-based services. See your instrument's Owner's Manual for more information.

On some instruments, your home WiFi router will need to support WPS to allow setup of the UD-WL01 to proceed.


  • Acoustic Pianos:
    • Disklavier Pianos:
      • Enspire Pro Pianos (UD-WL01 included with piano)
      • Enspire ST Pianos (UD-WL01 included with piano)
    • TransAcoustic:
      • TA2 Pianos (UD-WL01 not compatible with 1st generation SHTA pianos)
    • Silent Pianos:
      • SH2 Pianos (UD-WL01 not compatible with SH pianos)
      • SC2 Pianos (UD-WL01 not compatible with SG or SG2 pianos)
  • Clavinova PIanos:
    • CLP Series:
      • CLP-600 Series:
        • CLP-635
        • CLP-645
        • CLP-665GP
        • CLP-675
        • CLP-685
        • CLP-695GP
      • CLP-500 Series:
        • CLP-535
        • CLP-545
        • CLP-565GP
        • CLP-575
        • CLP-585
    • CSP Series:
      • CSP-150
      • CSP-170
    • CVP Series:
      • CVP-700 Series:
        • CVP-701
        • CVP-705
        • CVP-709
        • CVP-709GP
      • CVP-800 Series:
        • CVP-805
        • CVP-809
        • CVP-809GP
  • Home Keyboards & Workstations:
    • Tyros 5
    • PSR-S670
    • PSR-S775
    • PSR-S975
    • PSR-SX700
    • PSR-SX900
    • PSR-A3000
  • Synthesizers:
    • Motif XF6
    • Motif XF7
    • Motif XF8



  • Dimensions 69mm (W: including connector) ×15mm (H) ×31mm (D)


  • Note Standards: IEEE802.11b/g/n (IEEE802.11n 5GHz: not compatible), Range of transmit frequency (central frequency) : Models for United States and Canada: 2412-2462MHz (channels 1-11) Others: 2412-2472MHz (channels 1-13), Security: WEP, WPA-PSK (TKIP), WPA-PSK (AES), WPA2-PSK (AES), WPA/WPA2 mixed PSK
Product IDSUDWL01

Questions & Answers

Ask a Question:


The UD-WL01 is a USB adapter to connect certain Yamaha instruments to a network or to the internet rather than to a device (such as an iPad or iPhone).

The P-115 can't be connected to a network and won't work with the UD-WL01. But we think you want to connect your iPad to your P-115 in order to use the P-115's Digital Piano Controller app, or to use other music apps (such as Cubasis, Garageband and the various virtual instrument apps available)?

If that's the case, there are three ways to do this:

  1. Using a standard USB cable (USB 1.1 or USB 2.0) and Apple's own Lightning to USB Camera Adapter, you can connect the P-115 directly to an iPad, iPhone or iPod touch with a lightning socket:
  2. Using a Yamaha UD-BT01, you can connect the P-115 wirelessly to your iPad using Bluetooth MIDI (please note that an additional USB cable and USB mains power adapter are required)
  3. For older iOS devices with a 30-pin connector, the Yamaha i-UX1 cable can be used to directly connect to the P-115


Hi Trafford,

Thanks for getting in touch. The UD-WL01 isn't compatible with the YUS5 SH Silent Piano.

However, for wireless transmission of MIDI information (eg for recording and sequencing), our MD-BT01 Bluetooth MIDI connector can be used:
