Yamaha YEV-104 Full size, string, electric violin
Featuring stunning tone matched only by its looks and playablity, the four-string YEV-104 Electric Violin benefits from our advanced wood treatment and sound technologies.
Perfect for home practice, studio recording and live performance, it's an instrument that allows violinists to explore and enjoy genres beyond the classics.
Please note - This product may have been opened, returned by a customer, or refurbished. It could show minor cosmetic wear such as light marks or scratches, or be missing accessories or software. The original packaging or printed manual may not be included. However, it has been fully checked and works like new, offering you the chance to own a dependable product at a reduced price. It includes a 1-year warranty.
Features
Elegant Design With A Familiar Feel
The Möbius strip-like design looks stunning on stage - but also provides a familiar form for violinists making for a comfortable transition from acoustic to electric.
The nut height, bridge height and lower edge share the same relative dimensions with our traditional violins, making the YEV-104 instantly comfortable (and allows you to use your favourite chin and shoulder rests).
Crafted From Maple, Mahogany, Spruce & Walnut
We've crafted the YEV-104's 5-layer central body from hand-selected maple, mahogany and spruce woods - resulting in superb response and a natural tone.
We've created a 5-layer oil-finished walnut frame which gives the perfect balance between flexibility and strength - in a design that is not only striking, but also contributes to the YEV-104's natural resonance.
High Quality Pickup
Our flagship Silent Violin, the SV-250, features a specially-designed high output passive bridge pickup which exceeded expectations. We've used the same type of pickup for the YEV-104 - which on the new electric violin, effectively picks up the sound of the entire instrument, capturing the violin's response and all the expression and bowing nuances from the violinist.
Volume Control Bypass Switch
The built-in volume control is useful when practicing at home, giving you control over the sound. But on stage and in the recording studio, the engineer will usually want the strongest signal possible from your instrument. The bypass switch routes the raw signal from the pickup directly to the YEV-104's output instead of routing it through the instrument’s volume control. This delivers the violin’s full sonic potential, with rich lows and punchy impact to the tone - ideal for desk-based or post-production processing.
Specs
Size/Weight
| Dimensions | Width | 204mm |
|---|
| Height | 592mm |
|---|
| Depth | 111mm |
|---|
| Weight | Weight | approx. 550 g |
|---|
Body
| Size | 4/4 |
|---|
| Body | Spruce/Mahogany/Maple |
|---|
| Side/Frame | Walnut |
|---|
| Neck | Maple |
|---|
| Finger Board | Resin-Impregnated Wood |
|---|
Parts
| Bridge | Maple with built-in Piezo-electric Pickup |
|---|
| Tuning Pegs | Ebony |
|---|
| Tailpiece | Synthetic Resin (equipped with fine tuners) |
|---|
| Chin Rest | Bakelite |
|---|
| Strings | D"Addario Zyex |
|---|
Design/Architecture Detail
| Pick Up System | Bridge w/ Built-in Piezo-electric Pickup |
|---|
Functions
| Controls | Volume Control, Selector Switch (Volume Control activation switch) |
|---|
Storage and Connectivity
| Output | Passive Output (Φ6.3 Standard Monaural) |
|---|
