Line 6 HX Stomp Pedal

£450.00
incl. VAT
Ask us about our Price Promise - click here
HX Stomp Pedal
HX Stomp Pedal HX Stomp Pedal HX Stomp Pedal HX Stomp Pedal HX Stomp Pedal HX Stomp Pedal HX Stomp Pedal

Overview

Line 6's HX Stomp is a professional-grade multi-effects processor that delivers the sound of Helix amps, cabs, and effects in an ultra-compact pedal. Use it as a 'super stompbox', a backup or fly rig, an add-on tone expander when combined with other modellers, an audio interface - or even a complete guitar or bass rig.

The same HX Modelling technology which powers the flagship Helix guitar processor enables HX Stomp to run up to six processing blocks simultaneously, making it the most powerful and flexible stompbox-sized multi-effects processor available. HX Stomp is easy to operate thanks to its simple-but-powerful controls, colour display, and capacitive-sensing footswitches with colour-coded LED rings.

External control via MIDI and optional expression pedal and footswitch control provide additional flexibility, as does I/O that may be configured for sophisticated routing such as simultaneously feeding an amp and a FOH mixer, 4-cable method operation with an amplifier, and studio re-amping. Along with over 300 amps, cabs, and effects - even a looper-HX Stomp includes a legacy library of effects from Line 6 M-Series pedals, as well as from classic Line 6 stompbox modellers such as the DL4, MM4, FM4, and DM4. There are also presets created specifically for bass players, as well as individual bass amp and cab models.

The free HX Edit app offers preset librarian functionality and third-party IR loading.

  • Utilises the same HX Modelling as Helix
  • Over 300 effects and models from Helix, M-Series, and legacy Line 6 products
  • Up to 6 simultaneous amp, cab, and effect blocks (including a looper and IR loading)
  • 3 capacitive-sensing footswitches with color-coded LED rings facilitate fast editing
  • TRS dual expression pedal/footswitch input extends creative control capabilities
  • Stereo effects loop (mono/stereo TRS send + stereo returns) facilitates use with other pedals

Finance

Bring the dream within easier reach by spreading the cost with V12 Retail Finance. With a range of different finance schemes available, use the Finance Calculator below to choose a deposit amount and find out possible monthly payments.

Click here for more information

Finance agreements are available to UK residents aged 18 or over, subject to status.

Deposit £0.00 (0%)

Duration - please choose one


Representative Example

Purchase Price:£2,026.00 Deposit:£239.00
Amount of Credit:£1,787.00 24 Monthly Payments:£89.44
Total Repayable:£2,385.56 Agreement Duration:24 Months
Rate of Interest (Fixed):19.89% pa 19.89% APR Representative
Purchase Price:£2,289.00 Deposit:£260.00
Amount of Credit:£2,029.00 36 Monthly Payments:£73.64
Total Repayable:£2,911.04 Agreement Duration:36 Months
Rate of Interest (Fixed):19.89% pa 19.89% APR Representative
Purchase Price:£1,125.00 Deposit:£300.00
Amount of Credit:£825.00 6 Monthly Payments:£137.50
Total Repayable:£1,125.00 Agreement Duration:6 Months
Rate of Interest (Fixed):0% pa 0% APR Representative
Purchase Price:£3,545.00 Deposit:£240.00
Amount of Credit:£3,305.00 9 Monthly Payments:£367.22
Total Repayable:£3,545.00 Agreement Duration:9 Months
Rate of Interest (Fixed):0% pa 0% APR Representative
Purchase Price:£1,260.00 Deposit:£200.00
Amount of Credit:£1,060.00 12 Monthly Payments:£92.93
Total Repayable:£1,315.16 Agreement Duration:12 Months
Rate of Interest (Fixed):9.89% pa 9.89% APR Representative
Purchase Price:£1,499.00 Deposit:£199.00
Amount of Credit:£1,300.00 18 Monthly Payments:£83.12
Total Repayable:£1695.16 Agreement Duration:18 Months
Rate of Interest (Fixed):19.89% pa 19.89% APR Representative



Yamaha Music Europe GmbH (UK) trading as Yamaha Music London is registered in England and Wales BRO14498 at Sherbourne Drive, Tilbrook MK7 8BL. Yamaha Music Europe GmbH (UK) trading as Yamaha Music London acts as a credit broker and offers credit products from Secure Trust Bank PLC trading as V12 Retail Finance. Yamaha Music Europe GmbH (UK) trading as Yamaha Music London is authorised and regulated by the Financial Conduct Authority. Yamaha Music Europe GmbH (UK) FCA registration number is FRN688040. Credit provided subject to age and status.

V12 Retail Finance is registered in England and Wales with company number 4585692. Registered office: One Arleston Way, Solihull, B90 4LH. Authorised and regulated by the Financial Conduct Authority (FCA). V12 Retail Finance's FCA reference number is 679653.

Features

Additional features include a choice of true bypass and DSP bypass with trails, a stereo effects loop for patching other pedals into the signal chain and 4-Cable Method setups, a jack for connecting two external footswitches or expression pedals, extensive MIDI control, IR (impulse response) loading capabilities, and a multichannel 24-bit/96kHz USB audio interface. The free HX Edit app allows you to customize nearly every aspect of the pedal’s operation, create, save and load presets. It also provides preset librarian capabilities, IR loading, and more.

Intuitive Control & Editing

Despite its tiny size, HX Stomp is easy to both operate and program, thanks to its simple but powerful controls, 320 x 240-pixel colour LCD, and three capacitive-sensing footswitches with color-coded LED rings. External control via MIDI and optional expression pedal and footswitch control provide additional flexibility, as does I/O that may be configured for sophisticated routing such as simultaneously feeding an amp and a FOH mixer, 4-Cable Method operation with an amplifier, and easy studio re-amping.

Pristine Audio Quality

An industry-leading 123dB of dynamic range provides tremendous depth and ultra-low noise, while the highest-quality components guarantee unadulterated audio throughout - from inputs to outputs - whether feeding an amp, going direct to FOH, or recording in the studio.

A Complete Rig in a Pedal

Whether you need a backup for your Helix or other rig, a fly rig that will fit into a duffle bag with room to spare for cables and additional pedals, a convenient practice and rehearsal rig, or a complete guitar and effects studio recording setup - the HX Stomp multi-effects pedal provides the perfect solution. It even fits into the top pocket of a Helix Backpack.

Specs

DSP Processor

1x SHARC ADSP-21469 Processor, 450MHz

A/D/A Converters

24bit, 192KHz

Chassis

Cast Aluminium Alloy

Display

2.4” 320x240 Colour LCD

Capacitative Footswitches

x3

Power Supply

External PSU (Included)

Width

7.01”

Depth

4.69”

Height

2.6”

Weight

1.75lbs

Inputs

4x 1/4” Jack: Main L/R, Return L/R

Outputs

3x 1/4” Jack: Main L/R (Balanced), Stereo TRS Send

Headphone Output

Yes

FX Loops

TRS Stereo Send, 2x Return

Expression Pedal Connection

EXP 1/2 (TRS, Shared with Footswitch 4/5)

MIDI

IN, OUT/THRU

USB Audio Interface

8-In, 6-Out with re-amping (4 physical ins/outs)

USB MIDI

Yes

iOS Recording/Playback

Yes

Input Pad

Yes (Inputs set to Line Level)

Variable Impedance

Yes (Input L (Mono), Right)

123dB Dynamic Range

Yes (Input L (Mono), Right)

Preset Locations

126 (42 Banks x 3 Presets)

Snapshots

3 pre Preset

Processing Blocks

Up to 6 (free assignable, DSP permitting)

Signal Flow Paths

1 or 2 stereo

Amp Models

74

Cab Models

37

Effects Types

200 (123 HX, 77 Legacy)

User/3rd Party Impulse Responses

128x 1024-point or 2048-point mono

Simultaneous Impulse Response Blocks

2x 1024-point or 1x 2048 point, DSP permitting

Input Gate

x1

Looper

1 Switch Looper

Looper Memory

60 Seconds Mono or 30 Seconds Stereo (at full speed)

Global EQ

Yes

Dynamic Input Black Routing

Yes

Number of Footswitches

3 Capacitative; 2 external footswitches optional using TRS jack

Footswitch Mode Changeable With Feet?

Via external switch only

Swap all Stomp Assignments Option?

Yes

Footswitch Modes

Stomp, Scroll, Preset, Snapshot

Stomp Footswitch Types

Latching, Momentary

Maximum Number of Preset Switches

3

Maximum Number of Snapshot Switches

3

Maximum Number of Controllers

5 Physical + 94 via MIDI CC

Adjustment Parameters per Snapshot

64

Footswitch as Controller

8 per footswitch

Transmission of MIDI Bank/Program Change

Via Preset Recall Only

macOS/Windows Editor/Librarian/IR Loader Application

HX Edit 2.70 and higher

Dedicated Dry USB-Out Channels (For Re-Amping)

4

Preset List?

Yes

Quick-Reorder Presets?

Yes

MIDI Recall Indicator?

Yes

Repurpose Returns as Stereo Aux In

Yes

Product IDGHXSTOMP
Limited Shipping Please note that we are only able to deliver this item within the UK.
