Overview
Completely redesigned for the 3rd Generation of MG mixers, the compact MG10XU features 4 class leading Class A D-PRE microphone preamps, Yamaha's acclaimed SPX effects and a stereo USB audio interface.
Finance
Bring the dream within easier reach by spreading the cost with V12 Retail Finance. With a range of different finance schemes available, use the Finance Calculator below to choose a deposit amount and find out possible monthly payments.
Click here for more information
Finance agreements are available to UK residents aged 18 or over, subject to status.
Thank you for choosing V12 Retail Finance; you will now be taken to V12 Retail Finance's website to complete your finance application.
Yamaha Music Europe GmbH (UK) trading as Yamaha Music London is registered in England and Wales BRO14498 at Sherbourne Drive, Tilbrook MK7 8BL. Yamaha Music Europe GmbH (UK) trading as Yamaha Music London acts as a credit broker and offers credit products from Secure Trust Bank PLC trading as V12 Retail Finance. Yamaha Music Europe GmbH (UK) trading as Yamaha Music London is authorised and regulated by the Financial Conduct Authority. Yamaha Music Europe GmbH (UK) FCA registration number is FRN688040. Credit provided subject to age and status.
V12 Retail Finance is registered in England and Wales with company number 4585692. Registered office: Yorke House, Arleston Way, Solihull, B90 4LH. Authorised and regulated by the Financial Conduct Authority (FCA). V12 Retail Finance's FCA reference number is 679653.
Features
The MG10XU has the following features:
10-Channel Mixing Console Max. 4 Mic / 10 Line Inputs (4 mono + 3 stereo) 1 Stereo Bus 1 AUX (incl. FX) D-PRE mic preamps with an inverted Darlington circuit 1-Knob compressors High-grade effects: SPX with 24 programs 24-bit / 192kHz 2in / 2out USB Audio functions Works with the iPad (2 or later) through the Apple iPad Camera Connection Kit / Lightning to USB Camera Adapter Includes Cubase AI DAW software download version PAD switch on mono inputs +48V phantom power XLR balanced outputs Metal chassis Dimensions(W×H×D): 244 mm x 71 mm x 294 mm (9.6"x 2.8"x 11.6") Net Weight: 2.1 kg (4.63 lbs.)
Specs
Outline
Mixing capability On-board processors SPX algorithm: 24 programs I/O Phantom power +48 V Digital I/O USB Audio Class 2.0 compliant, Sampling Frequency: Max 192 kHz, Bit Depth: 24-bit Input Channels 4 3 Output Channels 2 1 1 1 Bus Stereo: 1, AUX[FX]: 1 Input Channel Function 26 dB (Mono) 80 Hz, 12 dB/oct (Mono) 1-knob compressor Threshold: +22 dBu to -8 dBu, Ratio: 1:1 to 4:1, Output level: 0 dB to 7 dB, Attack time: approx. 25 msec, Release time: approx. 300 msec Gain: +15 dB/-15 dB, Frequency: 10 kHz shelving Gain: +15 dB/-15 dB, Frequency: 2.5kHz peaking Gain: +15 dB/-15 dB, Frequency: 100 Hz shelving LED turns on when post EQ signal reaches 3 dB below clipping 2 x 7 -segment LED meter [PEAK, +10, +6, 0, -6, -10, -20 dB] General specifications
Total harmonic distortion 0.02 % @ +14dBu (20 Hz to 20kHz), GAIN knob: Min, 0.003 % @ +24dBu (1kHz), GAIN knob: Min Frequency response +0.5 dB/-1.0 dB (20 Hz to 48 kHz) , refer to the nominal output level @ 1 kHz, GAIN knob: Min Hum & noise level -128 dBu (Mono Input Channel, Rs: 150Ω, GAIN knob: Max) -102 dBu (STEREO OUT, STEREO LEVEL knob: Min) Crosstalk -83 dB Power requirements PA-10 (AC 38 VCT, 0.62A, Cable length = 3.6 m) or equivalent recommended by Yamaha Power consumption 22.9 W Dimensions 244 mm (9.6") 71 mm (2.8") 294 mm (11.6") Net weight 2.1 kg (4.63 lbs.) Accessories Others Operating Temperature: 0 to +40˚C
Product ID CMG10XUUKYEM
Limited Shipping
Questions & Answers
Question: What sort of USB lead do I need from the MG10XU mixer to my laptop?
Answer
Thank you for getting in touch. Usually, you'd need a standard USB-A-to-USB-B cable to connect the the MG10XU to most laptops. If your laptop only features USB-C ports, you'd either need a USB-B-to-USB-C cable or a USB-C-to-USB-A adapter/dongle.
Question: Hi, I'm new to this type of equipment. Could you please tell me whether I could plug in more than 1 pair of speakers. Also could the mixer's speaker output handle upto 700watt speakers? Thanks
Answer
Thank you for getting in touch. The MG10XU is a passive mixer - that is, it doesn't provide an amplified signal to any speakers which are connected.
Instead, it's designed to work either with active monitor speakers (for instance, Yamaha HS or MSP Series speakers for studio use), active PA speakers (for instance, Yamaha DXR Series PA speakers) or a power amplifier of some sort.
This means that you could connect speakers which themselves have 700w amplifiers built in, but you couldn't directly connect speakers rated up to 700w but which don't have their own built-in amplifiers.
Regarding the connections, the MG10XU has the following outputs:
Stereo Output, Left + Right:Either Jack or XLR connections This is typically used for the 'main' or front-of-house speakers in a system Monitor Output, Left + Right:Jack connections This is typically used for onstage monitors or a second set of speakers in a studio environment You can connect a pair of speakers to either or both. An example set up in a studio might be to have Yamaha HS7 Monitor speakers connected to the Stereo Left and Right connections via XLR cables, and - for comparison when mixing - a Yamaha HiFi (with its own speakers) connected to the Monitor Left and Right connections.
