Yamaha URX22C Audio / MIDI Interface - Black

Name: URX22C Audio / MIDI Interface - Black
Brand: Yamaha
SKU: CURX22C
Price: 169.00 GBP
Availability: OnlineOnly

£169.00

incl. VAT

Ask us about our Price Promise - click here

▶

Overview

Yamaha URX22C Audio/MIDI Interface in Black

YOU. FOR REAL.
Despite its minimalist footprint, the URX22C packs serious creative power.

With professional-grade sound, flexible DSP processing, and a full suite of Steinberg production tools, it gives you everything you need to record, produce, or stream from virtually anywhere - with impressive quality and ease.

2-in/2-out Audio/Midi Interface
USB-C with 32-bit/192 kHz
2x Combo/1x Hi-Z Inputs
Direct monitoring / Loopback
DC 5V
Steinberg Software Suite

Features

Minimum effort to maximize output.

Intuitive mixing with Yamaha’s custom DSP for recording and streaming.
Easy effect and volume control via dspMixFx.
High-quality recording and streaming with no efforts.
Smooth production with bundled Steinberg software.

lt alI starts with the sound.

32-bit/192 kHz high resolution audio support. Equipped with Yamaha D-PRE mic preamps.
Capture vocals and instruments with clarity and depth.

Simple operation. Serious functionality.
Simple design for fast, intuitive operation. Independent headphone and master volume controls. MIX knob blends input signal with playback audio. MONO button switches monitor sound between stereo/mono.

Everything you need. Anywhere you go.
Multitrack recording and editing with Cubase Al. Expand sounds with Steinberg Plus. Enhance streaming setup with MixKey (Beta). Integrated control with Elgato Stream Deck for dspMixFx.

Specs

I/O Connectors
Analog Input ~ 2 Mic/Line Combo, *Input 2 supports Hi-Z switch on input 2 for electric guitar
Analog Output ~ 2 TRS
USB TO HOST ~ 1 (USB Type-C, 32-bit)
Phones ~ 1 TRS (15 mW+15 mW @40 Ohm)
DC ~ 2 (Type-C USB bus power or Type-C USB DC IN)
MIDI ~ 1 IN / 1 OUT
User Interface ~ Dedicated software "dspMixFx", Input Gain, Mono/Stereo switch, Hi-Z for Input 2, +48V phantom power, Mix balance, Main Volume, Headphones Volume
Recording & Playback - USB ~ 2-track recording, 2-track playback
Sampling frequency rate ~ 192 kHz - 44.1 kHz
Frequency response ~ +0.0/-0.4 dB (20 Hz to 22 kHz)
Total harmonic distortion ~ [MIC/LINE/Hi-Z] 0.003 % at 1 kHz, 22 Hz/22 kHz BPF; [MAIN OUTPUT] 0.002 % at 1 kHz, 22 Hz/22 kHz BPF
Dynamic range ~ [MIC/LINE/Hi-Z] 106 dB, [MAIN OUTPUT] 107 dB
Gain range ~ 54 dB
Power requirements ~ DC5 V/0.9 A
Power consumption ~ 4.5 W
Dimensions ~ W 159 mm (6.3"), H 47 mm (1.9"), D 159 mm (6.3")
Net Weight ~ 1kg (2.0 lb)
Included Accessories ~ Setup Guide, Cubase AI License Card, Basic FX Suite License Card, Steinberg Plus License Card, USB Cable (3.1 Gen1, Type-C to Type-A, 1.0 m)
Operating temperature ~ 0 to + 40℃
Outline - Mixing Capacity
Input Channels ~ 2 Mono + 3 Stereo loopback + 1 FX
Mix Buses ~ 2 (1 MIX + 1 Streaming Mix)
Stereo Buses ~ 1
FX Buses ~ 1
On-board processors - DSP ~ PitchFix (Voice Changer), Sweet Spot Morphing Channel Strip (Comp & EQ), Guitar Amp Classics (Amp Simulator), Ducker, Compressor, Gate, Multi-Band Compressor, Delay, REV-X (Reverb)

Product ID	CURX22C
